Home > Products > DC/DC Converters > Wide input (50-350W)

Wide input (50-350W)

Product Search >>
Part No. Image Power(W) Input Volt(Vac/dc) Output Volt(vdc) Isolation Volt(Vac/dc) Efficiency(%) Package Size(mm) Certificate/
Standards		 Datasheet
/3D		 Samples Request
FD50-XXSXXB3(C)(-T)(-TS)
-/18-75 -/1500 50.8*25.4*9.5
FD50-48S24B3(C) 50 -/36-75 -/1500 90 50.8*25.4*9.5 -
FD50-48S15B3(C) 50 -/36-75 -/1500 90 50.8*25.4*9.5 -
FD50-48S12B3(C) 50 -/36-75 -/1500 89 50.8*25.4*9.5 -
FD50-48S05B3(C) 50 -/36-75 -/1500 87 50.8*25.4*9.5 -
FD50-48S3V3B3(C) 50 -/36-75 -/1500 87 50.8*25.4*9.5 -
FD50-24S24B3(C) 50 -/18-36 -/1500 90 50.8*25.4*9.5 -
FD50-24S15B3(C) 50 -/18-36 -/1500 90 50.8*25.4*9.5 -
FD50-24S12B3(C) 50 -/18-36 -/1500 89 50.8*25.4*9.5 -
FD50-24S05B3(C) 50 -/18-36 -/1500 90 50.8*25.4*9.5 -
FD50-24S3V3B3(C) 50 -/18-36 -/1500 87 50.8*25.4*9.5 -
FD50-XXSXXB3C2(-T)(-TS)
-/9-36 -/1500 50.8*25.4*11.8
FD50-18S24B3C2 50 -/9-36 -/1500 90 50.8*25.4*11.8 -
FD50-18S12B3C2 50 -/9-36 -/1500 90 50.8*25.4*11.8 -
FD50-18S05B3C2 50 -/9-36 -/1500 90 50.8*25.4*11.8 -
FD50-XXSXXB3(R)2(-XXX)
-/9-75 -/1500 50.8*25.4*11.8
FD50-36S24B3(R)2 50 -/18-75 -/1500 92 50.8*25.4*11.8 -
FD50-36S15B3(R)2 50 -/18-75 -/1500 92 50.8*25.4*11.8 -
FD50-36S12B3(R)2 50 -/18-75 -/1500 92 50.8*25.4*11.8 -
FD50-36S05B3(R)2 50 -/18-75 -/1500 91 50.8*25.4*11.8 -
FD50-18S24B3(R)2 50 -/9-36 -/1500 92 50.8*25.4*11.8 -
FD50-18S15B3(R)2 50 -/9-36 -/1500 92 50.8*25.4*11.8 -
FD50-18S12B3(R)2 50 -/9-36 -/1500 92 50.8*25.4*11.8 -
FD50-18S05B3(R)2 50 -/9-36 -/1500 91 50.8*25.4*11.8 -
FD50-110SXXB3C3-(XXX)
-/40 -160 1500/3000 50.8*25.4*13.0
FD50-110S48B3C3 50 -/40 -160 1500/3000 89 50.8*25.4*13.0 -
FD50-110S24B3C3 50 -/40 -160 1500/3000 89 50.8*25.4*13.0 -
FD50-110S15B3C3 50 -/40 -160 1500/3000 88 50.8*25.4*13.0 -
FD50-110S12B3C3 50 -/40 -160 1500/3000 88 50.8*25.4*13.0 -
FD50-110S05B3C3 50 -/40 -160 1500/3000 86 50.8*25.4*13.0 -
FD50-110S3V3B3C3 50 -/40 -160 1500/3000 85 50.8*25.4*13.0 -
FD60-XXSXXB3R2-(XXX)
-/9-75 1500/- 50.8*25.4*11.8
FD60-36S24B3R2 60 -/18-75 -/1500 93 50.8*25.4*11.8 -
FD60-36S15B3R2 60 -/18-75 -/1500 93 50.8*25.4*11.8 -
FD60-36S12B3R2 60 -/18-75 -/1500 93 50.8*25.4*11.8 -
FD60-36S05B3R2 60 -/18-75 -/1500 92 50.8*25.4*11.8 -
FD60-18S24B3R2 60 -/9-36 -/1500 93 50.8*25.4*11.8 -
FD60-18S15B3R2 60 -/9-36 -/1500 93 50.8*25.4*11.8 -
FD60-18S12B3R2 60 -/9-36 -/1500 93 50.8*25.4*11.8 -
FD60-18S05B3R2 60 -/9-36 -/1500 92 50.8*25.4*11.8 -
DD60-300S12G2N6
-/60-600 4000/- 126.5*76.0*40.5
DD60-300S12G2N6 60 -/60-600 4000/- 84 126.5*76.0*40.5 -
BK75-500SXXG(A)1N6
-/80-1000 4000/- 140.0*70.0*42.0
BK75-500S35G(A)1N6 75 -/80-1000 4000/- 89 140.0*70.0*42.0 -
BK75-500S32G(A)1N6 75 -/80-1000 4000/- 89 140.0*70.0*42.0 -
BK75-500S28G(A)1N6 75 -/80-1000 4000/- 89 140.0*70.0*42.0 -
BK75-500S24G(A)1N6 75 -/80-1000 4000/- 89 140.0*70.0*42.0 -
BK75-500S15G(A)1N6 75 -/80-1000 4000/- 87 140.0*70.0*42.0 -
BK75-500S12G(A)1N6 75 -/80-1000 4000/- 87 140.0*70.0*42.0 -
BK150-800SXXGA1D6
-/250-1500 4000/- 201.0*70.0*42.0
BK150-800S35GA1D6 150 -/250-1500 4000/- 90 201.0*70.0*42.0 -
BK150-800S32GA1D6 150 -/250-1500 4000/- 90 201.0*70.0*42.0 -
BK150-800S28GA1D6 150 -/250-1500 4000/- 89 201.0*70.0*42.0 -
BK150-800S24GA1D6 150 -/250-1500 4000/- 88 201.0*70.0*42.0 -
BK150-800SXXGB1D6
-/250-1500 4000/- 170.0*111.0*41.0
BK150-800S28GB1D6 150 -/250-1500 4000/- 89 170.0*111.0*41.0 -
BK150-800S24GB1D6 150 -/250-1500 4000/- 88 170.0*111.0*41.0 -
BK150-800S12GB1D6 150 -/250-1500 4000/- 84 170.0*111.0*41.0 -
BK150-800SXXGE1D6
-/250-1500 4000/- 201.0*70.0*42.0
BK150-800S35GE1D6 150 -/250-1500 4000/- 90 201.0*70.0*42.0 -
BK150-800S32GE1D6 150 -/250-1500 4000/- 90 201.0*70.0*42.0 -
BK150-800S28GE1D6 150 -/250-1500 4000/- 89 201.0*70.0*42.0 -
BK150-800S24GE1D6 150 -/250-1500 4000/- 88 201.0*70.0*42.0 -
BK150-800SXXGB1N6
-/250-1500 4000/- 170.0*111.0*41.0
BK150-800S28GB1N6 150 -/250-1500 4000/- 89 170.0*111.0*41.0 -
BK150-800S24GB1N6 150 -/250-1500 4000/- 88 170.0*111.0*41.0 -
BK200-800SXXG1N6
-/250-1500 4000/- 201.0*70.0*42.0
BK200-800S24G1N6 200 -/250-1500 4000/- 91 201.0*70.0*42.0 -
BK200-750SXXG1N6
-/300-1500 4000/- 215.0*125.0*50.0
BK200-750S48G1N6 200 -/300-1500 4000/- 87 215.0*125.0*50.0 -
BK200-750S32G1N6 200 -/300-1500 4000/- 87 215.0*125.0*50.0 -
BK200-750S24G1N6 200 -/300-1500 4000/- 86 215.0*125.0*50.0 -
BK200-800SXXGB1N6
-/250-1500 4000/- 168.0*111.2*42.5
BK200-800S24GB1N6 200 -/250-1500 4000/- 91 168.0*111.2*42.5 -
BK350-800SXXG1N6
-/300-1500 4000/- 215.0*125.0*50.0
BK350-800S32G1N6 350 -/300-1500 4000/- 92 215.0*125.0*50.0 -
BK350-800S28G1N6 350 -/300-1500 4000/- 92 215.0*125.0*50.0 -
BK350-800S24G1N6 350 -/300-1500 4000/- 92 215.0*125.0*50.0 -
