Home > Products > AC/DC Converters > DIN-Rail Power Supply(20-500W)

DIN-Rail Power Supply(20-500W)

Product Search >>
Part No. Image Power(W) Input Volt(Vac/dc) Output Volt(vdc) Isolation Volt(Vac/dc) Efficiency(%) Package Size(mm) Certificate/
Standards		 Datasheet
/3D		 Samples Request
SIM-100
90-264/127-370 - 30*125.1*110
SIP45
85-264/120-370 4000/- 35.0*90.0*54.5
SIP45-48 45.12 85-264/120-370 4000/- 91 35.0*90.0*54.5 -
SIP45-24 44.88 85-264/120-370 4000/- 90 35.0*90.0*54.5 -
SIP45-12 30 85-264/120-370 4000/- 88 35.0*90.0*54.5 -
SIP45 20 85-264/120-370 4000/- 82 35.0*90.0*54.5 -
SIP20
85-264/120-370 4000/- 17.5*90.0*54.5
SIP20-48 20.16 85-264/120-370 4000/- 87 17.5*90.0*54.5 -
SIP20-24 20.16 85-264/120-370 4000/- 86 17.5*90.0*54.5 -
SIP20-12 18 85-264/120-370 4000/- 85 17.5*90.0*54.5 -
SIP20-5 12.5 85-264/120-370 4000/- 80 17.5*90.0*54.5 -
SIP75
85-264/120-370 4000/- 52.5*90.0*54.5
SIP75-48 75.36 85-264/120-370 4000/- 91 52.5*90.0*54.5 -
SIP75-36 74.88 85-264/120-370 4000/- 90 52.5*90.0*54.5 -
SIP75-24 75.36 85-264/120-370 4000/- 90 52.5*90.0*54.5 -
SIP75-15 60 85-264/120-370 4000/- 88 52.5*90.0*54.5 -
SIP75-12 60 85-264/120-370 4000/- 88 52.5*90.0*54.5 -
SIP75-5 40 85-264/120-370 4000/- 85 52.5*90.0*54.5 -
SIM150
90-264/127-370 3000/- 30.0*125.1*110.0
SIM150-48 150.24 90-264/127-370 3000/- 91 30.0*125.1*110.0 -
SIM150-36 151.2 90-264/127-370 3000/- 90 30.0*125.1*110.0 -
SIM150-24 150 90-264/127-370 3000/- 89 30.0*125.1*110.0 -
SIM150-15 135 90-264/127-370 3000/- 86 30.0*125.1*110.0 -
SIM150-12 120 90-264/127-370 3000/- 86 30.0*125.1*110.0 -
SIM-500(R)
90-264/127-370 3000/- 50.0*125.1*110.0
SIM500-48 499.2 90-264/127-370 3000/- 94 50.0*125.1*110.0 -
SIM500-24 499.2 90-264/127-370 3000/- 93.5 50.0*125.1*110.0 -
SIM500-12 360 90-264/127-370 3000/- 91.5 50.0*125.1*110.0 -
